6V DC SONGLE Power Relay

6V DC SONGLE Power Relay

LE 6.00

Click here to be notified by email when 6V DC SONGLE Power Relay becomes available.


This is a high quality  6V DC songle power relay

  • Rated load:  10A 250VAC/28VDC,10A 125VAC/28VDC
  • Contact resistance: <=100m (ohm)
  • Electrical life: 100,000
  • Mechanical life: 10,000,000
  • Coil rated voltage: 3-48VDC
  • Coil power: 0.36W, 0.45W
  • Coil pick-up voltage: <=75%
  • Coil drop-out voltage: >=10%
  • Ambient temperature: -25 degrees Celsius to +70 degrees Celsius
  • Coil and contacts:1500VAC/min
  • Contact and contacts: 1000VAC/min
  • Insulation resistance: >=100M ohm
  • Mounting form: PCB
  • Weight: 10 g
  • Outline dimensions:19mm x 15.5mm x 15mm

For relay datasheet, please click here
